TL45L-Pro-28W-220V
Product
information
| Product number： | TL45L - 28W |
| Track System: | 6 wire, 4 wire, 3 wire |
| Input Voltage : | 220-240V |
| Dimming: | On/Off，Triac，1-10V Knob，DALI |
| Light source: | COB LED |
| luminaire Lifetime： | L80，50.000H（Ta=25°C） |
| Rotation Angle : | 350° |
| Tilting Angle : | 90° |
| Protection Level: | IP20 |
| Material: | AL |
| Fitting Colors: | 9016 Sandy White / 9017 Sandy Black |
| Storage Temperature: | -40˚C ~ +80 ˚C |
| Working Temperature: | -20˚C ~ +30 ˚C |
| Warranty: | 5 years |
Packaging
information
| N.W. lamp (Kg)： | 0.73 |
| G.W. Carton (Kg)： | 12 |
| Master carton dimensions(mm)： | L520*W420*H365 |
| Quantity per carton(pcs)： | 16 |
System
overview
| Beam | Watt | CRI | Luminous | CCT | Code |
| 14 | 28W | 90 | 2542 lm | 4000K | TL45L-28G40-14 |
| 2383 lm | 3000K | TL45L-28G30-14 | |||
| 24 | 28W | 90 | 2497 lm | 4000K | TL45L-28G40-24 |
| 2341 lm | 3000K | TL45L-28G30-24 | |||
| 36 | 28W | 90 | 2554 lm | 4000K | TL45L-28G40-36 |
| 2394 lm | 3000K | TL45L-28G30-36 | |||
| 45 | 28W | 90 | 2780 lm | 4000K | TL45L-28G40-45 |
| 2606 lm | 3000K | TL45L-28G30-45 | |||
| 60 | 28W | 90 | 2473 lm | 4000K | TL45L-28G40-60 |
| 2318 lm | 3000K | TL45L-28G30-60 |
Downloads
Size
Need more informations? Contact us
